the material thickness for the chariot grab handle
the material thickness for the railing hinge post
Rename your files according to the Excel names
101.4 Chariot Drag Stand Cross Member missing
101.3 2 Chariot Drag Stand(Right) filename and drawing name
|
101.3R |
2 |
Chariot Drag Stand(Left) |
|
|
101.3L |
2 |
Chariot Drag Stand(Right) |
|
101.5 Chariot Grab Handle filename and drawing name
106.6 latch plate File name Latch
201.1Drag Wear Bar Qty 4
202.2Side Panel Post.pdf not right drawing
205.3 Upper Bracket-Outside(left) file number not on drawing
There should be a right and left drag stand part.
Check the file name and the correct part for these pdfs.
Please reply to this email with a 10-4 ( Affirmative/Message received)
